Description
Hose and fitting identification guide, fluid and air-quality table, repair checklist and an RFQ for hydraulic and compressed-air repairs.
Who it’s for
Maintenance teams that repair hydraulic equipment, lifts, presses and compressed-air systems.
What it helps you avoid
- Replacement hoses with the wrong pressure rating or fittings
- Contaminated hydraulic fluid
- Compressed air leaks and wet air damaging tools
- Unsafe use of compressed air for cleaning
What’s inside
- Who this package is for
- What it helps you avoid
- Product specification table
- Standards & listings quick reference
- Take-off & sizing worksheet
- Supplier quote comparison
- Paste-ready RFQ scope language
- Install & commissioning checklist
- Maintenance schedule
- Common mistakes to avoid
Product classes covered
- Hydraulic hose assemblies
- Fittings and adapters
- Hydraulic fluid
- Filters
- FRL units
- Air hose and couplers
- Cylinders and seal kits
Standards referenced
- Hydraulic hose: SAE J517
- Fluid cleanliness: ISO 4406
- Compressed air quality: ISO 8573-1
- Compressed air for cleaning: OSHA 29 CFR 1910.242(b)
- Fluid power symbols: ISO 1219
Format: PDF download, available right after checkout. It’s a planning and purchasing aid, not engineering or a code review. Confirm requirements with your local code, the authority having jurisdiction and the manufacturer.
