Description
Nameplate capture sheet, replacement selection table, efficiency checklist and RFQ for circulators, pumps and general-purpose motors.
Who it’s for
Maintenance teams and facility managers replacing failed pumps or motors who need the right unit the first time.
What it helps you avoid
- Replacement motors with the wrong frame, shaft or enclosure
- Pumps selected off the old nameplate without checking the duty point
- Non-potable pumps used in domestic water
- Ignoring efficiency rules and VFD compatibility
What’s inside
- Who this package is for
- What it helps you avoid
- Product specification table
- Standards & listings quick reference
- Take-off & sizing worksheet
- Supplier quote comparison
- Paste-ready RFQ scope language
- Install & commissioning checklist
- Maintenance schedule
- Common mistakes to avoid
Product classes covered
- Circulator pumps
- Inline / end-suction pumps
- Sump and sewage pumps
- General-purpose motors
- Variable frequency drives
- Couplings and belts
- Mechanical seals
Standards referenced
- Motors: NEMA MG 1 (frames, ratings)
- Motor efficiency: DOE 10 CFR 431 / NEMA Premium
- Pumps: Hydraulic Institute standards
- Potable water pumps: NSF/ANSI 61 and 372
- Motor circuits: NFPA 70 (NEC) Article 430
Format: PDF download, available right after checkout. It’s a planning and purchasing aid, not engineering or a code review. Confirm requirements with your local code, the authority having jurisdiction and the manufacturer.
